POWER WHEELCHAIR SM5

Motor:
- Direct Current / Permanent Magnet
- Traction by reducer with coupled electromagnetic brake

Batteries:
-
Sealed (02 batteries)
-
2 X 12 volts 45 Ah


Electronics:
- Electronic Control of speed
- Joystick Control
- Battery Charger 90 – 240 V ~ Full range (Average charge time:  8 to 10 hours)

Transmission:
-
Gearbox motor (motor reducer) of 450W each

Frame:
- Monoblock chassis in reinforced steel of 1’ (01 inch)
- Removable armrests with adjustable height
- Footrest with platform and manual leg-lift
- Headrest with Adjustable Height and Depth
- Rigid seat
- Backrest in nylon canvas with manual tilt
- Padded cushion (Foam: 5 cm, density 45)
- Calf rest

Brake:
-Electromagnetic

Front Wheels
- PU foam-filled 8’ tires
- Aluminum wheels with puncture-resistant gray tires

Rear Wheels
- PU foam-filled 13’ tires
- Aluminum rear wheels with puncture-resistant gray tires
- Training/Support wheels
- Anti-tip device: Diameter 50 mm

Dimensions:
- Seat width: 41/45/50 cm;
- Backrest Height: 45/50 cm;
- Seat Length: 40/45 cm
- Total width:  62/66 cm;
- Total weight: 90 kg

  Operation:
- Maximum Speed: 8 km/h
- Range: 25 km (User weight: 80 kg, on a flat floor with new stationary batteries at full charge)
- Weight capacity:  130 kg  maximum (on a flat floor with 02 new batteries at full charge)

ITENS OPCIONAIS:
• Electric tilt-in-space
• Electric leg angle adjustment
• Electric recline angle adjustment


Click here for more details




ANVISA Registration #: 80791830006

Seat Mobile Brasil, the manufacturer of the power wheelchair SM5, guarantees the frame of the equipment free of manufacturing defects for a period of 01(one) year (90 days plus 275 days) from the date of the purchase indicated on the invoice issued by the manufacturer and/or the distributor, or authorized resellers.
